Displayed pictures are for reference only, equipment is as given in the offer.
Technische Daten
Typmilling machine / machining center
Number22727
CategoryMilling machines
ProducerFulland
ModelFMC 1400
Year2006
Travel axes1400 x 760 x 700 mm [X×Y×Z]
Number of axis4
ControlFANUC Serie 18i-MB
spindle chuckBT 40
Speed range to10000 U/min
Speed range from1 U/min
spindle revolutions10000 rpm
table size Y700 mm
table size X1500 mm
max. workpiece weight700 kg
tool changer24 - time
input Power 15 kW
spindle cooling
control Fanuc
Beschreibung
The FULLAND FMC 1400 is a 4-axis CNC vertical machining center with FANUC 18i-MB control.
It offers travel ranges of 1400 x 760 x 700 mm, a table size of 1500 x 700 mm and a table load capacity of 700 kg. The spindle reaches up to 10,000 rpm with BT40 tool holder and the tool changer provides 24 positions. The machine is robustly built and suitable for precise machining of medium to large workpieces. Internal coolant is installed.
